5 SUBPAC X1 Live version l The Patented Wearable Audio Tactile Bass System

Initially designed for musicians, this version of the SUBPAC meets the requirements of public spaces.
The “Live” version features an on-board UHF transmission device, customised connectivity and professional battery management.

• 2 patented tactile transducers integrated in each SUBPAC vibrating waistcoat, the reference in tactile music reproduction.
• Increased frequency band: 1Hz -> 250 Hz.
• Encapsulated new generation radio frequency (UHF) reception system with secure connectivity for unified vibration and volume control.
• Range up to 1km spherical (or up to 500 meters from the transmitter) with simplified frequency control on 3 available channels (one colour/channel).
• Optimised overall autonomy (more than 8 hours of use).
• Disinfectable polymer.

PATENTED IMMERSIVE LIVE CASE – SX5 version
Latest generation. Customised professional system.

• Designed to optimise storage, recharging, transport and loans.
• Optimum protection against the elements, dust and impact.
• Polymer and fibreglass injection moulding.
• Waterproof, dustproof and chemical resistant (IP67 certified).
• Automatic pressure relief valve for safe transport and long term storage.
• Easy opening double latches.
• Temperature range: -30 / 90 °c (-22 / 194 °f).
• Load tested soft grip handle, double padlock holes, stackable locking system, nylon pins, corrosion resistant.
• Customised integration and technical layout, compartmentalisation of the solution.
• Miniaturisation of the boxes – 4th evolution.
• Intelligent and flexible holding of all equipment.
• Customised foaming of the sides (HD and honeycomb type), anti-fungal treatment of wood and foam.
• Labelling of each element.
• External dimensions of 816mm x 540mm x 306mm (L x W x H)
• Total weight with all equipment : 20kg (44 lbs).

PATENTED UNIFIED CHARGING MODULE INTEGRATED TO THE CASE

• NF certified electrical safety system, compliant with the safety standards of the ERP (establishments receiving the public).
• Allows the simultaneous and secure charging of all the Live version backpacs and the radio frequency transmission devices (UHF).
• The system protects against damage caused by overloading, short-circuitingor earth leakage.
• This certified system guarantees an optimal life span of all your equipment.
• Intelligent control and distribution management per device type.
• Casing of the load modules.
• Integration of an automatically controlled main electrical control panel for monitoring the various parameters of the unified load.
• Tests under normal/critical load conditions, overload/priming simulation for a ready-to-use solution.

TIMMPI UHF Transmitter – TX-50RF

• Certified Radio Frequency Transmission (863.5MHz / 864.5MHz).
• Range up to 1km spherical.
• 3 channels available.

5 X Induction Neck Loop TIMMPI-IL-01 (in option)

• 3.5mm jack allows wireless connection to hearing aids equipped with a “T” coil.
• The listeners plug the loop into the SUBPAC LIVE, then slide the loop around their neck, the “T” coil of the hearing instrument picks up the sound and then transmits it back to the listener.

Buying or Renting

• We adapt the most suitable model for your budget.
